01Motorized Z-Axis Lift
The machine automatically adjusts the worktable to accommodate different material thicknesses, with a lifting height of up to 200 mm.
Laser Type
Sealed CO2 laser tube
Laser Power
40 W / 60 W / 80 W (optional)
Machine Size
1360 × 900 × 950 mm
International Certifications
Advantages of the equipment
02Automatic Focusing
One-touch focusing maintains a consistent focal distance. No manual refocusing is required when switching thicknesses, improving throughput and shift-to-shift consistency.
03Taiwan Hiwin Linear Guideway
Adopts high-precision Taiwan Hiwin ball-type linear guideways, ensuring accurate positioning and reduced wear for long-term accuracy.
04RECI CO2 Laser Tube (40-80 W)
Features high output power density, a concentrated beam, and a uniform spot profile, resulting in high working efficiency and fast cutting speeds. Manufactured with specialized techniques, the laser beam is sharply focused to produce narrow marking lines, deep engravings, high resolution, and crisp text and graphics.
Sample Display
Applications
Technical Parameters
| Laser - Type | Sealed CO2 laser tube |
| Laser Power | 40W 60W 80W (optional) |
| Engraving Area | 600mm x 400mm |
| Worktable | Motorized up down table |
| Whole Machine Size | 1360*900*950mm |
| Engraving Speed | 0-36,000mm/min |
| Resetting Positioning Accuracy | ±0.05mm |
| Working Voltage | AC 110-220V±10%,50-60Hz |
| Gross Power | <1000W |
| Operating Temperature | 0-45°C |
| Operating Humidity | 5-95% |
| Minimum Shaping Character | English 1x1mm |
| Graphic Format Supported | BMP, PLT, DST, DXP, and AI |
| Driving System | stepper |
| Cooling Mode | Water-cooling and protection system |
| Auxiliary Equipments | Exhaust-fans, air-exhaust pipe |
| Controlling Software | DSP control system |
| Compatible Software | CorelDRAW / AutoCAD / Photoshop |
