01Motorized Z-Axis Lift
180 mm motorized Z-axis stroke accommodates various material thicknesses and fixture heights. With autofocus, it reduces manual focusing and setup time.
Laser Type
Sealed CO2 laser tube
Laser Power
80 W / 100 W / 130 W / 150 W (optional)
Machine Size
1880 × 1549 × 1075 mm
International Certifications
Advantages of the equipment
02Automatic Focusing
One-touch focusing maintains a consistent focal distance. No manual refocusing is required when switching thicknesses, improving throughput and shift-to-shift consistency.
03Four-Side Access Openings
Access doors on all four sides support oversized workpieces and step-cutting of long panels, enhancing fixturing flexibility and material utilization.
04RECI CO2 Laser Tube (80-150 W)
Delivers stable beam quality and high focal energy density. With appropriate optics and airflow, acrylic achieves near-polished cut edges, while wood/MDF cuts are clean and engravings are crisp.
Sample Display
Applications
Technical Parameters
| Parameter | Specification |
| Laser Type | Sealed CO2 laser tube |
| Laser Power | 80 W / 100 W / 130 W / 150 W (optional) |
| Work Area | 1300 mm × 900 mm |
| Machine Size | 1880 × 1549 × 1075 mm |
| Max Cutting Speed | 0-24,000 mm/min |
| Repeatability | ±0.05 mm |
| Power Supply | AC 110-220 V ±10%, 50-60 Hz |
| Total Power Consumption | < 1,500 W |
| Operating Temperature | 0-45 °C |
| Operating Humidity | 5-95% |
| Minimum Character Size English: | 1 × 1 mm |
| Work Table | 180 mm lift platform |
| Drive System | Stepper motor |
| Cooling | Water cooling with overheat protection |
| Auxiliary Equipment | Exhaust fan and ducting system |
| Control System | DSP control system |
| Compatible Software | LightBurn / RDWorks / CorelDRAW / AutoCAD / Photoshop |
