01Taiwan Hiwin Linear Guideway
Adopts high-precision Taiwan Hiwin ball-type linear guideways, ensuring accurate positioning and reduced wear for long-term accuracy.
Laser Type
Sealed CO2 laser tube
Laser Power
60 W / 80 W / 100 W / 130 W / 150 W (optional)
Machine Size
3520 × 1940 × 1300 mm
International Certifications
Advantages of the equipment
02RECI CO2 Laser Tube (60-150 W)
Features high output power density, a concentrated beam, and a uniform spot profile, resulting in high working efficiency and fast cutting speeds. Manufactured with specialized techniques, the laser beam is sharply focused to produce narrow marking lines, deep engravings, high resolution, and crisp text and graphics.
03WIFI Control
Enables remote monitoring, parameter adjustment, and troubleshooting. One PC can control multiple machines for enhanced convenience and efficiency.
04RECI CO2 Laser Tube (80-150 W)
Features a multi-stage filtration process: a bag filter captures large particles, a HEPA filter removes particles down to 0.03 um, and an activated carbon adsorption system eliminates odors and harmful fumes.
Sample Display
Applications
Technical Parameters
| Parameter | Specification |
| Laser Type | Sealed CO2 laser tube |
| Laser Power | 80 W / 100 W / 130 W / 150 W (optional) |
| Work Area | 1300 mm × 900 mm |
| Machine Size | 1880 × 1549 × 1075 mm |
| Max Cutting Speed | 0-24,000 mm/min |
| Repeatability | ±0.05 mm |
| Power Supply | AC 110-220 V ±10%, 50-60 Hz |
| Total Power Consumption | < 1,500 W |
| Operating Temperature | 0-45 °C |
| Operating Humidity | 5-95% |
| Minimum Character Size English: | 1 × 1 mm |
| Work Table | 180 mm lift platform |
| Drive System | Stepper motor |
| Cooling | Water cooling with overheat protection |
| Auxiliary Equipment | Exhaust fan and ducting system |
| Control System | DSP control system |
| Compatible Software | LightBurn / RDWorks / CorelDRAW / AutoCAD / Photoshop |
Get a Quote
Today
Leave your basic information, and we will contact you as soon as possible to provide detailed information and a quote.
